A spec that says only “silicone oil” is half a spec. A 10 cSt fluid and a 100,000 cSt fluid are the same chemistry and almost nothing alike in use: one runs off a part like water, the other clings like honey. Viscosity, measured in centistokes (cSt), is the variable that decides what a silicone oil will actually do, and choosing it is most of the buying decision.
The short version: silicone oil viscosity is set by the length of the polymer chain and runs from about 5 cSt to over 1,000,000 cSt. Low-viscosity grades (about 5 to 50 cSt) are thin and spread, wet, and release; mid-viscosity grades (about 100 to 1,000 cSt) are the general lubrication, damping, and polish fluids; high-viscosity grades (about 5,000 cSt and up) are thick, used for heavy damping, antifoam bases, and additives. Higher viscosity means more film, cling, and damping; lower viscosity means more spreading and penetration.
What viscosity changes
Across the range, the chemistry is constant (polydimethylsiloxane, CAS 63148-62-9, PubChem; also named dimethicone); only the chain length, and therefore the viscosity, changes. As viscosity rises, the fluid forms a thicker, more persistent film, clings and damps more, and spreads and penetrates less. As it falls, the fluid spreads and wets faster, penetrates finer gaps, and leaves a thinner film. A useful trait of silicone is its low viscosity-temperature coefficient: its viscosity changes less with temperature than mineral oils, so a grade behaves consistently across a wide thermal range.
The grade ladder
| Viscosity range | Behavior | Typical use |
|---|---|---|
| Low: ~5 to 50 cSt | Thin, spreading, fast-wetting, more volatile | Release agents, dielectric/carrier fluids, wetting, light lubrication |
| Mid: ~100 to 1,000 cSt | Balanced film and flow | General lubrication, damping, polishes, water-repellent treatments |
| High: ~5,000 to 100,000 cSt | Thick, strong film and cling | Heavy damping, mechanical fluids, antifoam compound bases, additives |
| Very high: ~100,000 to 500,000+ cSt | Near-gum, very high cling | Damping, additives, processing aids |
These ranges overlap in practice, and grades are sometimes blended to hit a target viscosity.
Common cSt grades at a glance
The stocked dimethicone (PDMS) fluids run as a continuous ladder on one chemistry. The table below maps each common grade to its character and where it is typically used; click a grade for its full specifications.
| Grade | Character | Typical use |
|---|---|---|
| 0.65 cSt | Volatile, ultra-low (hexamethyldisiloxane, MM) | Fast-flashing carrier and cleaning fluid, dry feel |
| 1.0 cSt | Volatile, ultra-low (octamethyltrisiloxane, MDM) | Volatile carrier, quick spread and dry-down |
| 1.5 cSt | Ultra-low, fast-spreading | Carrier/diluent, low-temp dielectric/heat-transfer, anti-spatter, antifoam base |
| 2 cSt | Ultra-low, very light | Carrier/diluent, low-temp dielectric/heat-transfer, anti-spatter, antifoam base |
| 5 cSt | Very low, mobile | Light spreading, anti-spatter, carrier, dielectric |
| 10 cSt | Low, mobile | Lubrication, mold release, polishes |
| 50 cSt | Low to medium | Release, lubrication, dielectric fluids |
| 100 cSt | Mobile fluid | Spreading, carrier fluids, light lubrication |
| 200 cSt | Balanced mid-range fluid | General-purpose conditioning/slip, release, lubrication, polishes, antifoam base |
| 350 cSt | Medium fluid | General-purpose lubrication, release, polishes |
| 500 cSt | Medium-heavy fluid | Durable release, lubrication, polishes, dielectric, light damping |
| 1,000 cSt | Higher-viscosity fluid | Release agents, damping, mechanical fluids |
| 5,000 cSt | Heavy fluid | Mechanical damping, heavy lubrication, durable polishes, dielectric |
| 10,000 cSt | Heavy fluid | Damping, anti-vibration, additive base |
| 12,500 cSt | Heavy fluid | Damping, anti-vibration, specialty lubrication |
| 60,000 cSt | Very heavy fluid | Damping, vibration control, additive base |
| 100,000 cSt | Very heavy fluid | High damping, specialty compounding |
| 500,000 cSt | Near-gum, very high viscosity | High-damping and specialty compounding |
For the full domestic-stock range, packaging, and specialty silicones beyond the straight fluids, see the bulk silicone oil supplier hub.
How to choose
Match the viscosity to the function:
- Spreading, wetting, or release (mold release, carrier, surface treatment): a low-viscosity grade that spreads and leaves a thin film.
- Lubrication: a mid-viscosity grade that holds a durable film without being draggy; lower for fine mechanisms, higher for load and cling.
- Damping: a mid-to-high grade; the higher the viscosity, the heavier the damping.
- Foam control: a high-viscosity grade as the base of an antifoam or defoamer compound.
- Dielectric or heat-transfer service: a grade qualified for that duty, which is a different, low-moisture specification from a general-purpose oil of the same viscosity, covered in silicone heat transfer oil.
When in doubt, test two adjacent grades on the actual part or system; viscosity selection is best confirmed by trial. The applications are detailed in industrial uses of silicone oil.
Buying silicone oil by grade
RawSource supplies silicone oil as dimethicone (PDMS) across the full viscosity range, from volatile grades such as Silicone Oil 1.5 cSt and 5 cSt, through mid grades like 200 cSt, 350 cSt, 500 cSt and 1,000 cSt, to heavy grades such as 5,000 cSt and up to 100,000 cSt and beyond, in drums, IBC totes, and pallets, with CoA documentation. The complete ladder and packaging are on the bulk silicone oil supplier hub.
Tell us your application and target viscosity, and request samples of two adjacent grades to confirm the right one on your own system. The fundamentals are in what is silicone oil.
Frequently asked questions
What does cSt mean for silicone oil?
cSt is centistokes, the unit of kinematic viscosity. It indicates how thick the silicone oil is: a low cSt fluid is thin and spreads, a high cSt fluid is thick and clings. The grade you order is defined by its cSt value.
What viscosity silicone oil is best for lubrication?
A mid-viscosity grade, roughly 100 to 1,000 cSt, is the general lubrication range. Use lower viscosity for fine mechanisms and faster penetration, and higher viscosity for more film, load, and cling. Validate on the actual part.
What silicone oil viscosity is used for mold release?
A low-viscosity grade, often in the 5 to 100 cSt range, spreads and releases well and leaves a thin film. The exact grade depends on the substrate and process; test on your tooling.
Does silicone oil viscosity change with temperature?
Less than mineral oils. Silicone has a low viscosity-temperature coefficient, so a given grade holds its behavior across a wider temperature range, which is part of why it is used where stable viscosity matters.
Which silicone oil viscosity is used for damping?
Mid-to-high viscosity grades, from around 1,000 cSt up to 100,000 cSt or more, are used for viscous damping. The higher the viscosity, the heavier the damping effect. Select to the mechanism and damping target.
Editorial note. This article is general technical guidance for industrial and professional buyers. Viscosity ranges and grade-to-use mappings are typical, generalized guidance to validate for your application; the Certificate of Analysis governs the grade and viscosity you buy. Silicone oil is an industrial PDMS fluid, low in toxicity and chemically inert but environmentally persistent and not a biodegradable or “green” product, and not represented for food or medical use. Always consult the current Safety Data Sheet (SDS) before handling. RawSource makes no warranty, express or implied, and assumes no liability for use of this information.
