脱水およびハイドレート抑制用グリコール — TEG、MEG、DEG — に加え、天然ガスおよびパイプライン用途の熱力学的ハイドレート防止剤としての methanol。
脱水用グリコールは、天然ガスから水蒸気を除去し、通常およそ7 lb/MMscfというパイプラインの水分含有量規格を満たすようにする吸湿性のジオールです。 この用途における標準的な吸収塔溶剤はtriethylene glycolです。関連する第二の役割はハイドレート制御で、湿性ガスラインに注入されたmonoethylene glycolがガスハイドレートの生成温度を低下させます。グリコールは用途に合わせて選定してください—脱水塔にはTEG、ハイドレート抑制にはMEGです。
TEG dominates gas dehydration because it regenerates cleanly at the reboiler temperatures a glycol unit can reach. Diethylene glycol is the older, lower-boiling option and still appears where regeneration temperature is limited, though it carries more vaporization loss. Both run as the working fluid of a closed contactor-and-regenerator loop, so makeup volumes are modest once a unit is charged. Specify TEG for new dehydration service and reserve DEG for existing low-temperature units.
For hydrate inhibition the real choice is MEG versus methanol. MEG can be recovered and recycled through a reclamation unit, which favors continuous, high-volume injection on subsea tiebacks and long flowlines. Methanol is cheaper per gallon and effective for startup or intermittent duty, but it is usually lost to the hydrocarbon and water phases and can create downstream specification problems. Choose MEG when injection is continuous and recovery pays back; choose methanol for short, low-volume duty.
